Pick & Place Machine - Samsung SM482 Flexible Mounter

Highly reliable SM482 is the latest generation of Full Vision pic and place machines f ROM Samsung Techwin.
Cost of ownership is extremely low due to the simple yet reliable X/Y/Z structure.
Easy to use software allows users to quckly learn the machine and get the most from it. Standard component library has more than 1800 shapes and the polygonic algorithm automatically detects component outlines on difficult components.

Features:
Built in vacuum pump making air consumption just 50Nl/min! ! ! !
Easily Identifieable Feeders
Adaptive Pick Up
Front and back operation as standard
Large PCB Size of 460mm X 400mm
0201 component recognition as standard
120 X 8mm Feeder Capacity
High Accuracy ± 50µ @3σ /Chip
Small Footprint of just 1650mm X 1690mm X 1535mm
4.7kVA Max Power

Placement Rate: 28'000cph optimum
Placement Accuracy: ± 50µ @3σ /Chip
± 30µ @3σ /QFP
Component Range: 0201~22mm² By flying vision
~55mm² Or 75mm long connectors
Max Height = 15mm
PCB Size: 460mm X 400mm
PCB Thickness: 0.38 ~ 4.2mm
Feeder Capacity: 120 X 8mm

Options:
01005 Placement by optional Fly Camera
32mm² @0.3mm Lead Pitch by optional 35mm Fixed Camera
Board Size 510mm X 460mm
Board Size 610mm X 510mm
Board Size 740mm X 460mm
Intelligent Feeder and Parts system
Feeder Docking Carts
Flux Dipping Feeder
